Tibia & Femur Nail
Tibia Type
Femur Type
Features
- MFDS. Lisence#
- 13-1608
- Meterial
- Titanium (ASTM F136)
- EDI Code
- C3112180(Tibia), C3111180(Femoral)
Details
✅ 장골 골절에 최적화된 Nail
✅ 안전성을 높인 의료용 티타늄 적용
product information
Specification table
■ Tibia Nail
| Length(mm) | Ø8 | Ø9 | Ø10 | Ø11 | Ø12 | ||
| Unreaming | Reaming | Unreaming | Reaming | Reaming | Reaming | Reaming | |
| 270 | N7501 | N7501R | N7511 | N7511R | N7521 | N7531 | N7541 |
| 285 | N7502 | N7502R | N7512 | N7512R | N7522 | N7532 | N7542 |
| 300 | N7503 | N7503R | N7513 | N7513R | N7523 | N7533 | N7543 |
| 315 | N7504 | N7504R | N7514 | N7514R | N7524 | N7534 | N7544 |
| 330 | N7505 | N7505R | N7515 | N7515R | N7525 | N7535 | N7545 |
| 345 | N7506 | N7506R | N7516 | N7516R | N7526 | N7536 | N7546 |
■ Femur Nail
| Length(mm) | Ø10 | Ø11 | Ø12 | Ø13 |
| 320 | N5501 | N5511 | N5521 | N5531 |
| 340 | N5502 | N5512 | N5522 | N5532 |
| 360 | N5503 | N5513 | N5523 | N5533 |
| 380 | N5504 | N5514 | N5524 | N5534 |
| 400 | N5505 | N5515 | N5525 | N5535 |
| 420 | N5506 | N5516 | N5526 | N5536 |
| 440 | N5507 | N5517 | N5527 | N5537 |
Additional Specifications
■ End Cap
| Spec | Cat. No |
| L-0 | N0301 |
| L-5 | N0302 |
| L-10 | N0303 |
■ Instruments
| Description | Cat. No |
| Pocket | IN75-02 |
| Awl - Curved | IN75-04 |
| Skin Protector | IN75-05 |
| Guide Pin Holder | IN75-06 |
| Target Device for Tibia | IN75-07 |
| Supine Driver | IN75-08 |
| Extractor Large Bolt | IN75-10 |
| Wrench Spanner | IN75-11 |
| Slide Hammer | IN75-12 |
| Nail impactor | IN75-13 |
| Drill Guide 4.5 | IN75-14 |
| Drill Guide 5.0 | IN75-15 |
| Drill Sleeve | IN75-16 |
| Sleeve Trocar | IN75-17 |
| Drill Bit 4.5 | IN75-18 |
| Drill Bit 5.0 | IN75-19 |
| Depth Gauge | IN75-21 |
| Awl | IN75-22 |
| Driver | IN75-23 |
| Universal Wrench | IN75-24 |
| Ball Tip Guide | IN75-25 |
| Straight Guide | IN75-26 |
| Flexible Reamer Shaft | IN75-28 |
| Reamer Tip 9.0 | IN75-29 |
| Reamer Tip 9.5 | IN75-30 |
| Reamer Tip 10.0 | IN75-31 |
| Reamer Tip 10.5 | IN75-32 |
| Reamer Tip 11.0 | IN75-33 |
| Reamer Tip 11.5 | IN75-34 |
| Reamer Tip 12.0 | IN75-35 |
| Reamer Tip 12.5 | IN75-36 |
| Reamer Tip 13.0 | IN75-37 |
| Reamer Tip 13.5 | IN75-38 |
| Nail Instrument Case | IN75-36 |
| Pocket | IN55-01 |
| Target Device | IN55-02 |
| Drill Guide 6.0 | IN55-03 |
| Drill Bit 6.0 | IN55-04 |
| Reamer Tip 14.0 | IN55-05 |
| Reamer Tip 14.5 | IN55-06 |
■ Screw
5.0mm Locking Screw 25 ~ 80mm
6.0mm Locking Screw 25 ~ 70mm
(*단위 : 5mm)
